LF-TOP-RGB-S
Architectural Flexible Linear
Flexible Linear
CATEGORYInterior
PRODUCT RANGELUMENFLEX
COLORWhite
IP68 rated, top emitting flexible colour changing LED strip, offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Single layer injection moulded connections ensure IP68 integrity. 2-Step MacAdams Ellipse binning strategy for colour consistency. Available in lengths up to 10M. Please click here to view length matrix and additional information.
Construction
InstallationSURFACE / RECESSED
ConstructionPVC & RESIN
Width / Depth11.5 MM
Height21 MM
FinishWHITE
IP RatingIP68
IK RatingIK08
Operating Ambient Temperature-20˚C - +40˚C
Cut Points100 MM
Max Cut Length10000 MM
Optical Performance
Wattage12W/M
CCTRGB
CRICRI > 80
Binning2 STEP MACADAMS
Beam Angle120°
ChipsetSMD5050 TRI-CHIP
Electrical
Constant Current or VoltageCONSTANT VOLTAGE
Voltage24V
Cable Length300 MM
Dimensions
Light Distribution
120°
| Item No. | Driver | Control | Max. Length | Datasheet |
|---|---|---|---|---|
| 15210 | ORLRPV2435 | Switched | 2.5M | |
| 15214 | ORLRPV2460 | Switched | 5M | |
| 15199 | ORLRPV24100 | Switched | 8M | |
| 15203 | ORLRPV24150 | Switched | 10M |
